Magnetic Field Patterns in oil

Summary:
Make patterns with iron filings in oil. Back with colour to make an art piece to photograph.
Science content (2016 curriculum):
Physics: Motion and Forces, Newton’s Laws, Gravity (K, 2, 6)
Lessons activity is in:
Materials:
  • glass plates e.g. from picture frames
  • vegetable oil, or other clear oil
  • iron filings
  • pipette
  • magnets, weaker ceramic ones work best
  • coloured paper
  • camera to record artwork
Procedure:

This activity is messy, and best done in a tray. Probably not suitable for a whole class, but for breakout groups with an attending adult.

Add a puddle of oil to one glass plate, spread out a little, then sprinkle iron filings on it.
Slowly lower the second glass plate, to avoid air bubbles. Add more oil from the edges with a pipette if necessary.
Move the top glass plate in a circular motion over the lower glass plate, to spread out the iron filings.
Use a magnet over the top glass plate to draw patterns in the iron filings.
Once a design is completed, slide a coloured piece of paper below the lower glass plate, being careful not to get oil on it, then photograph.

Notes:

A simpler way to capture iron filings art - make iron filings pattern on a paper plate, spray with vinegar (will make rust). Allow to dry then brush of filings to leave the field pattern in rust. https://scientistinresidence.ca/pdf/physical-science/Concepts%20in%20Ele...

Grades taught:
Gr 4
Gr 5
Teacher:
Ingrid
Teaching site:
ingridscience afterschool
Activity originally developed and delivered:

ingridscience afterschool
